1
|
Unit Size
|
1200X1200X680mm
|
|
2
|
Packing Size
|
1360X1360X810mm
|
|
3
|
Unit Weight
|
230Kg
|
|
4
|
Cutting Width
|
800mm
|
|
5
|
Driving Speed
|
5Km/H
|
|
6
|
Cutting Height
|
20-150mm remote control
|
|
7
|
Grade Ability
|
45°
|
|
8
|
Engine
|
Loncin 452CC
|
|
9
|
Walking motor
|
4pcs*500w
|
|
10
|
Oli Capacity
|
1.2L
|
|
11
|
Gasoline Capacity
|
7.1L
|
|
12
|
Cutting Speed
|
2800㎡/H
|
|
13
|
Start
|
Electronic start up/Remote start
|
|
14
|
Packing Weight
|
280Kg
|
|
15
|
Certification
|
With CE/EPA/Euro5
|
Scenes to be used
- Grassland: cleaning of dead grass, opening fire isolation zone;
-
Roads: pruning road green belts, side slopes, parks and other municipal green spaces, lawns, road snow removal, etc.;
-
Forestry: stubble shrubs, clean up combustibles under forests, and open up fire barriers;
-
Levees: clean up weeds and shrubs in the embankment and discover potential safety hazards in time to avoid accidents Orchard；
-
Farm: move the lawn, remove weeds, and free your hands.
|
|
HY-500
|
HY-550CJ
|
HY-500P
|
HY-550CB
|
|
Overall size
|
930*860*580
|
930*860*580mm
|
900*930*520mm
|
930*860*580mm
|
|
Package size
|
1060*960*810
|
990-990-810mm
|
950*980*670mm
|
990*990*810mm
|
|
Machine wei ght
|
150KG
|
130kg
|
140kg
|
140kg
|
|
Packing weight
|
196KG
|
176kg
|
170kg
|
182kg
|
|
Cutting width
|
50CM
|
550mm
|
500mm
|
550mm
|
|
Walking speed
|
3.5KM/H
|
5Km/h
|
4km/h
|
5Km/h
|
|
Cutting height
|
2-15CM
|
20-150mm
|
20-150mm
|
20-150mm
|
|
Climb ing angle
|
45°
|
45°
|
45°
|
45°
|
|
Engine
|
YAMAHA MA190/LONCIN 196
|
LONCIN/YAMAHA/KOHLER
|
RATO/YAMAHA/KOHLER
|
LONCIN/YAMAHA/KOHLER
|
|
Horsepower
|
7.5HP
|
7/8/9HP
|
9HP
|
7/8/9HP
|
|
Fuel tank capacity
|
1.2L
|
1.2L
|
1.2L
|
1.2L
|
|
Chassis Adjustable
|
Automatic
|
Automatic
|
Automatic
|
Automatic
|
|
|
HY-500E
|
HY-600KC
|
HY-800K(A)
|
HY-800K(B)
|
|
Overall size
|
930*860*580mm
|
1040*1040*520mm
|
1070*1230*670mm
|
1200*1200*640mm
|
|
Package size
|
990*990*810mm
|
1090*1090*690mm
|
1140*1300*800mm
|
1320*1320*800mm
|
|
Machine wei ght
|
140kg
|
150KG
|
240kg
|
240kg
|
|
Packing weight
|
210kg
|
190KG
|
310kg
|
310kg
|
|
Cutting width
|
550mm
|
600mm
|
800mm
|
800mm
|
|
Walking speed
|
5Km/h
|
20-130mm
|
20-150mm
|
20-150mm
|
|
Cutting height
|
20-150mm
|
4KM/H
|
4km/hour
|
4km/hour
|
|
Climb ing angle
|
45°
|
45°
|
45°
|
45°
|
|
Engine
|
/
|
RAT0225CC EU5/EPA
|
LONCIN
|
LONCIN
|
|
Horsepower
|
/
|
9.5HP
|
16HP
|
16HP
|
|
Fuel tank capacity
|
/
|
1.2L
|
7.1L
|
7.1L
|
|
Chassis Adjustable
|
Automatic
|
Automatic
|
Electric One Button Start
|
Electric One Button Start
|
|
|
HY-1000(K)
|
HY-500
|
HY-550W
|
550WB
|
|
Overall size
|
1430*1250*650 mm
|
980*880*460mm
|
980*880*460mm
|
1150*870*640mm
|
|
Package size
|
1480*1300*820 mm
|
1030*930*630mm
|
1030*930*630mm
|
1220*930*810mm
|
|
Machine wei ght
|
300KG
|
105kg
|
105kg
|
140kg
|
|
Packing weight
|
360KG
|
135kg
|
135kg
|
182kg
|
|
Cutting width
|
1000mm
|
500mm
|
500mm
|
550mm
|
|
Cutting height
|
20-150mm
|
20-150mm
|
20-150mm
|
20-150mm
|
|
Walking speed
|
5km/h
|
5km/h
|
5km/h
|
5Km/h
|
|
Climb ing angle
|
45°
|
35°
|
35°
|
30°
|
|
Engine
|
LONCIN
|
Rato 225cc
|
RATO/YAMAHA/KOHLER
|
LONCIN/YAMAHA/KOHLER
|
|
Horsepower
|
22HP
|
9.5HP
|
7/8/9HP
|
7/8/9HP
|
|
Fuel tank capacity
|
7.1L
|
1.2L
|
1.3L
|
1.2L
|
|
Start
|
Remote control start and stop
|
Remote control start and stop
|
Remote control start and stop
|
Remote control start and stop
|
